The rotating tables on the left and right side rotate synchronously to prevent missetting and mishandling of the petri dish.
Multiple samples can be continuously and automatically measured based on specific measurement conditions. Measurement speed is 100 dishes per hour. In addition, by attaching QR codes to the lid of each petri dish, it enables to automatically input sample names, lot information, measurement information, etc. Even when a QR code is not used, sample names, lot information, and measurement conditions can be easily entered with the input assist function or the continuous copy function.
Opening and closing of petri dish lid is automated. By removing the petri dish lid, high-precision measurement is possible even when there is dew condensation, print marks, label, etc on the lid.
Even if there are print marks on the dish part of the petri dish, they can be erased by lighting method, realizing highly accurate measurement.
It is able to can set the upper and lower limits of the number of colonies to be allowed for each measurement condition. This allows you to quickly check NG samples. You can also save sample original and result images for review and remeasurement.
You can save data to a storage device on the network. You can also check remote data over the network. During measurement, you can check the measured results.
A colony counter equipped with a camera with 3 to 20 mega pixels can be selectable as the measurement unit according to the sample. The PSF series is equipped with an advanced image processing function that satisfies the highest precision colony counting function. By registering measurement conditions in advance, measurement can be performed on any petri dish under any measurement conditions.
Various customizations are possible with the technical capabilities cultivated through factory automation. Please feel free to contact us for customizations.
Please consult us even if more than 600.
Not only φ90mm circular petri dishes but also various petri dishes are available.
| Model | PDH-521T9 |
|---|---|
| Dimensions of main unit | W1,100 x D960 X H1,850 mm |
| Weight | 410Kg |
| Power source | AC φ3 200V, special class D grounding work required. |
| System configuration | Main unit, colony counter, control PC, monitor |
| Front operation monitor | 10-inch color touch panel |
| Rotation tables | Each rotating table used to put and take out petri dishes has 5 racks, and each racks can hold up to 21 petri dishes. |
| Maximum samples | 105 petri dishes |
| Measurement object | Viable bacteria Colonies, Plaques, etc. |
| Measurement speed | Up to 100 petri dish/hour |
| Petri dish identification | Barcode /QR code reader, manual input is also available. |
| Colony counter | Select from PSF-1100/2100/5100/7100 |
| Camera | Color CMOS |
| Number of camera pixels | 3–20 mega pixels * |
| Calculated resolution | 28～67μm * |
| PC specs for colony counter | Depends on the type of colony counter. |
| Operating environment | 10-35℃, 20-80 % humidity Select a place there is no abnormal vibration, and small amount of dust and dirt. |
*Depends on the type of colony counter.
